#include <GTreeNodeT.hh>

Inheritance diagram for GTreeNodeT< T >:

Public Member Functions
template<class Q >
bool	IsInstanceOf () const

template<class Q >
bool	IsInstanceOf ()

virtual GTreeNodeT< T > *	Clone () const =0

virtual const char *	ClassName () const

Constructors, affectation, destructor
	GTreeNodeT ()

	GTreeNodeT (const GTreeNodeT< T > &original)

virtual	~GTreeNodeT ()

Tree structure functions
virtual void	SetParent (GTreeBranchT< T > *parent_ptr)

virtual void	SetListIter (GListIterT< GTreeNodeT< T > > *iter_ptr)

virtual const GTreeBranchT< T > *	GetParent () const

virtual GTreeBranchT< T > *	GetParent ()

virtual const GTreeNodeT< T > *	GetRoot () const

virtual GTreeNodeT< T > *	GetRoot ()

virtual bool	IsBranch () const

virtual bool	IsLeaf () const

void	SetUserData (void *data)

void *	GetUserData () const

virtual GListIterT< GTreeNodeT < T > >	GetListIter () const

Tree structure exploration
virtual GTreeNodeT< T > *	NextNode ()

virtual GTreeLeafT< T > *	FirstLeaf ()

virtual GTreeLeafT< T > *	NextLeaf ()

virtual GTreeNodeT< T > *	FindNode (const string &name)

virtual GTreeBranchT< T > *	FindBranch (const string &name)

Tree construction functions
virtual GTreeBranchT< T > *	AddBranch (const string &bname)

virtual GTreeBranchT< T > *	AddBranch (const string &parent, const string &bname)

virtual GTreeLeafT< T > *	AddLeaf (T &object_ref)

virtual GTreeLeafT< T > *	AddLeaf (const string &parent, T &object_ref)

virtual GTreeLeafT< T > *	AddLeaf (T *object_ptr)

virtual GTreeLeafT< T > *	AddLeaf (const string &parent, T *object_ptr)

Element information
u_int	GetLevel () const

virtual string	GetFullName () const

virtual u_int	GetLeafCount () const =0

virtual u_int	GetLeafTotalCount () const =0

Creation of objects structures from the tree
virtual GNamedListT< T > *	CreateList ()

virtual GTreeNodeT< GItem > *	CreateItemTree () const =0

virtual GItemList *	CreateItemList ()

Print out
virtual void	Print (FILE *fp=stdout, const string &prefix="", bool info=false) const =0

Public Member Functions inherited from GNamed
template<class Q >
bool	IsInstanceOf () const

template<class Q >
bool	IsInstanceOf ()

	GNamed (const string &object_name="")

	GNamed (const GNamed &object)

virtual	~GNamed ()

GNamed &	operator= (const GNamed &object)

virtual const string &	Name () const

virtual string &	Name ()

virtual string	GetName () const

virtual string	GetInfo () const

virtual void	SetName (const string &object_name)

int	Compare (const GNamed &object) const

int	CompareDict (const GNamed &object) const

bool	operator== (const GNamed &object) const

bool	operator!= (const GNamed &object) const

bool	operator< (const GNamed &object) const

bool	operator> (const GNamed &object) const

bool	operator<= (const GNamed &object) const

bool	operator>= (const GNamed &object) const

Static Public Member Functions
static const char *	StaticClassName ()

Static Public Member Functions inherited from GNamed
static const char *	StaticClassName ()

Protected Attributes
GTreeBranchT< T > *	parent
	Parent element of the tree.

GListIterT< GTreeNodeT< T > > *	list_iter
	Pointer to the iterator in parent list.

void *	user_data
	Pointer to a additional user data.

Protected Attributes inherited from GNamed
string	name
	Object name.

Detailed Description

template<class T>
class GTreeNodeT< T >

Template abstract base class to define a tree structure of objects. The tree elements inherit from the GNamed class for objects identification.

The main elements of a tree structure are:

the branches (GTreeBranchT), that can contain other (sub-)branches and/or leaves;
the leaves (GTreeLeafT), that is a terminal node, with a pointer to an object of class T.

The template class provide functions to dupplicate the tree structure, with GItem object pointing to the original tree class T objects.

Warning:

Do not use "/" (slash) character in names of objects from tree structure, unless explicitely specifying sub-tree branches.

See GCpp template classes for more information about the template classes.

Constructor & Destructor Documentation

template<class T >

GTreeNodeT< T >::GTreeNodeT ( )

inline

Default constructor.

References GDebugConst, GTreeNodeT< T >::list_iter, GTreeNodeT< T >::parent, and GTreeNodeT< T >::user_data.

template<class T >

GTreeNodeT< T >::GTreeNodeT ( const GTreeNodeT< T > & original )

inline

Copy constructor. The pointer to the parent is not copied: if an element is copied, it is outside the tree structure.

Parameters

original object to copy

References GDebugConst, GTreeNodeT< T >::list_iter, GTreeNodeT< T >::parent, and GTreeNodeT< T >::user_data.

template<class T >

GTreeNodeT< T >::~GTreeNodeT ( )

inlinevirtual

Destructor.

References GDebugDest.

Member Function Documentation

template<class T >

GTreeBranchT< T > * GTreeNodeT< T >::AddBranch ( const string & bname )

inlinevirtual

Add a sub-branch in current node (redefined in branch).

Parameters

bname name of the sub-branch

Reimplemented in GTreeBranchT< T >.

template<class T >

GTreeBranchT< T > * GTreeNodeT< T >::AddBranch	(	const string &	parent,
		const string &	bname
	)

virtual

Add a sub-branch in current tree.

Parameters

parent	parent branch name
bname	name of the sub-branch

References GTreeBranchT< T >::AddBranch().

template<class T >

GTreeLeafT< T > * GTreeNodeT< T >::AddLeaf ( T & object_ref )

inlinevirtual

Add a leaf in current node (redefined in branch). The object is not adopted by the created leaf.

Parameters

object_ref object given by reference

Reimplemented in GTreeBranchT< T >.

template<class T >

GTreeLeafT< T > * GTreeNodeT< T >::AddLeaf	(	const string &	parent,
		T &	object_ref
	)

virtual

Add a leaf in current tree. The object is not adopted by the created leaf.

Parameters

parent	parent branch name
object_ref	object given by reference

References GTreeBranchT< T >::AddLeaf().

template<class T >

GTreeLeafT< T > * GTreeNodeT< T >::AddLeaf ( T * object_ptr )

inlinevirtual

Add a leaf in current node (redefined in branch). The object is adopted by the created leaf.

Parameters

object_ptr object given by pointer

Reimplemented in GTreeBranchT< T >.

template<class T >

GTreeLeafT< T > * GTreeNodeT< T >::AddLeaf	(	const string &	parent,
		T *	object_ptr
	)

virtual

Add a leaf in current tree. The object is adopted by the created leaf.

Parameters

parent	parent branch name
object_ptr	object given by pointer

References GTreeBranchT< T >::AddLeaf().

template<class T >

GItemList * GTreeNodeT< T >::CreateItemList ( )

virtual

Create a list of GItem, for each leaf of the tree structure. The GItem elements refer to the data associated to the leaves. The resulting list must be deleted by the calling function.

References GItemList::AddItem(), GTreeLeafT< T >::GetDataPtr(), GTreeLeafT< T >::GetName(), GTreeNodeT< T >::NextLeaf(), and GItem::SetInfo().

template<class T >

GNamedListT< T > * GTreeNodeT< T >::CreateList ( )

virtual

Create a list of objects, for each leaf of the tree structure. The list does not adopt the object pointers.

References GListT< T >::Append(), GTreeLeafT< T >::GetDataPtr(), and GTreeNodeT< T >::NextLeaf().

template<class T >

GTreeBranchT< T > * GTreeNodeT< T >::FindBranch ( const string & name )

virtual

Function searching for a branch in the tree structure. The function calls FindNode and checks that the node found is a branch.

Parameters

name	name of the searched branch.

References GTreeNodeT< T >::IsBranch().

template<class T >

GTreeNodeT< T > * GTreeNodeT< T >::FindNode ( const string & name )

virtual

Function searching for a node in the tree structure. If name starts with '/', search from the tree root. Names "." and ".." respectively correspond to current and parent nodes. Note that the root name should not appear when searching from tree root: it is refered to by the '/' at name beginning.

Parameters

name	name of the searched node.

References GListT< GTreeNodeT< T > >::Begin(), GTreeNodeT< T >::FindNode(), GNamed::GetName(), GTreeNodeT< T >::IsBranch(), and GListT< GTreeNodeT< T > >::Null().

Referenced by GTreeNodeT< T >::FindNode().

template<class T >

GTreeLeafT< T > * GTreeNodeT< T >::FirstLeaf ( )

virtual

Return the first node that is a leaf in the tree structure.

References GTreeNodeT< T >::IsInstanceOf(), and GTreeNodeT< T >::NextLeaf().

template<class T >

string GTreeNodeT< T >::GetFullName ( ) const

virtual

Return the full name of the node, including parent nodes. The name of root is not included.

template<class T>

virtual u_int GTreeNodeT< T >::GetLeafCount ( ) const

pure virtual

Function returning the number of leaves.

Implemented in GTreeBranchT< T >, and GTreeLeafT< T >.

template<class T>

virtual u_int GTreeNodeT< T >::GetLeafTotalCount ( ) const

pure virtual

Function returning the total number of leaves, recursively in the tree structure.

Implemented in GTreeBranchT< T >, and GTreeLeafT< T >.

template<class T >

u_int GTreeNodeT< T >::GetLevel ( ) const

Return the hierarchy level of the object (0 means top element).

References GTreeNodeT< T >::GetParent().

template<class T >

GListIterT< GTreeNodeT< T > > GTreeNodeT< T >::GetListIter ( ) const

inlinevirtual

Return the list iterator (to this element) from the parent branch, if defined, else return a null iterator.

Referenced by GTreeNodeT< T >::NextNode().

template<class T >

const GTreeBranchT< T > * GTreeNodeT< T >::GetParent ( ) const

inlinevirtual

Return the tree element parent pointer.

Referenced by GTreeNodeT< T >::GetLevel(), GTreeNodeT< T >::NextNode(), GTreeLeafT< T >::Print(), and GTreeBranchT< T >::Print().

template<class T >

GTreeBranchT< T > * GTreeNodeT< T >::GetParent ( )

inlinevirtual

Return the tree element parent pointer.

template<class T >

const GTreeNodeT< T > * GTreeNodeT< T >::GetRoot ( ) const

inlinevirtual

Return the root (top tree) element pointer.

References GTreeNodeT< T >::GetRoot().

Referenced by GTreeNodeT< T >::GetRoot().

template<class T >

GTreeNodeT< T > * GTreeNodeT< T >::GetRoot ( )

inlinevirtual

Return the root (top tree) element pointer.

template<class T >

void * GTreeNodeT< T >::GetUserData ( ) const

inline

Get the pointer to the additionnal user data.

template<class T >

bool GTreeNodeT< T >::IsBranch ( ) const

inlinevirtual

Return true if the node is a branch.

Reimplemented in GTreeBranchT< T >.

Referenced by GTreeBranchT< T >::CreateFolderTree(), GTreeNodeT< T >::FindBranch(), and GTreeNodeT< T >::FindNode().

template<class T>

template<class Q >

bool GTreeNodeT< T >::IsInstanceOf ( ) const

inline

Macro from GCpp library that defines the following functions:

ClassName(): return the real class name of the object
StaticClassName(): return the used class name of the object (that may be a base class of the real object).
IsInstanceOf<T>(): return true if the current object is an instance of the template class name argument
Clone(): return an allocated copy of the object.

Referenced by GTreeNodeT< T >::FirstLeaf(), and GTreeNodeT< T >::NextLeaf().

template<class T >

bool GTreeNodeT< T >::IsLeaf ( ) const

inlinevirtual

Return true if the node is a leaf.

Reimplemented in GTreeLeafT< T >.

template<class T >

GTreeLeafT< T > * GTreeNodeT< T >::NextLeaf ( )

virtual

Return the next node taht is a leaf.

References GTreeNodeT< T >::IsInstanceOf(), and GTreeNodeT< T >::NextNode().

Referenced by GTreeNodeT< T >::CreateItemList(), GTreeNodeT< T >::CreateList(), and GTreeNodeT< T >::FirstLeaf().
